Solomix 1 stationary feed mixer for silage
The Solomix 1 STAT for silage is a stationary feed mixer, featuring a single vertical auger and a chain or belt conveyor. The mixed hay or grass is discharged by the chain conveyor into a spreader, a robot, or onto a belt system. This diet feeder is suitable for both large and small-scale livestock breeders and is available in volumes ranging from 7-14 m³ (for cu.ft. visit our US website). Its simplicity means any maintenance costs are minimal and the machine operates at high efficiency. Use the link to discover more about the unique features of our feed mixers.
Read the testimonial: How to use automation in order to improve feeding accuracy and efficiency
Photos
Standard features
- One door of the E-motor
- Three supports adjustable in height
- Wear ring
- Trioform auger knives short
- Tub, auger(s), chassis and wear ring out of St. 52
Technical specifications
If you want the values in cubic feet, please visit our US website, click here
| Solomix 1 stationary feed mixer for silage (VL) | 700 VL | 1000 VL | 1200 VL | 1400 VL |
|---|---|---|---|---|
| Capacity m3 | 7 | 10 | 12 | 14 |
| Length (excl. motor) m | 3.15 | 3.46 | 3.52 | 3.78 |
| Length (incl. motor) m | 4.09 | 4.27 | 4.26 | 4.31 |
| Width m | 2.15 | 2.29 | 2.30 | 2.44 |
| Height* m | 2.08-2.38 | 2.45-2.75 | 2.65-2.95 | 2.70-3.00 |
| Nett weight (ex. motor and motor frame) kg | 2.300 | 3.500 | 3.900 | 4.000 |
| Number of auger knife positions per auger | 8 | 8 | 8 | 12 |
| Number of auger knives fitted | 5 | 5 | 5 | 9 |
| Auger diameter mm | Ø 2000 | Ø 2200 | Ø 2200 | Ø 2440 |
| Required electrical installation | Frequency drive | Frequency drive | Frequency drive | Frequency drive |
.
| Solomix 1 stationary feed mixer for silage (ZK) | 700 ZK | 1000 ZK | 1200 ZK | 1400 ZK |
|---|---|---|---|---|
| Capacity m3 | 7 | 10 | 12 | 14 |
| Length (excl. motor) m | 2.91 | 3.32 | 3.43 | 3.78 |
| Length (incl. motor) m | 3.85 | 4.12 | 4.18 | 4.31 |
| Width m | 2.22 | 2.38 | 2.38 | 2.44 |
| Height* m | 2.08-2.38 | 2.45-2.75 | 2.65-2.95 | 2.70-3.00 |
| Nett weight (ex. motor and motor frame) kg. | 2.350 | 3.350 | 3.950 | 4.000 |
| Number of auger knife positions per auger | 8 | 8 | 8 | 12 |
| Number of auger knives fitted | 5 | 5 | 5 | 9 |
| Auger diameter mm | Ø 2000 | Ø 2200 | Ø 2200 | Ø 2440 |
| Required electrical installation | Frequency drive | Frequency drive | Frequency drive | Frequency drive |
* Supports are set to 800 mm height as standard
If you want the values in cubic feet, please visit our US website, click here
